Jablotron JA-63KRX

Specificatii tehnice

JA-63 "Profi" este o centrala programabila cu o arhitectura compacta. Prin programare, aceasta poate fi impartita in doua sectiuni de operare separate (cu o zona comuna). Are o sursa de alimentare incorporata si loc suficient pentru o baterie de back-up (12V, 1,3Ah sau 2.6Ah) in cutia centralei.

Placa de baza a JA-63K are 4 intrari pe cablu cu trigerare programabila (NC, EOL sau dublu EOL) si reactii programabile.

Modelul JA-63KR (echipat cu modul de comunicatie radio "R") are 16 zone fara fir. Pe fiecare zona se pot invata pana la 2 detectori JA-60 (cel mult 32 detectori). Modelul JA-63KR are, In total, 20 de zone (4 cu fir si 16 fara fir). De asemenea, se pot invata pana la 8 telecomenzi (control de la distanta pe linie telefonica sau tastaturi fara fir), o sirena JA-60 fara fir si un numar nelimitat de module de iesire fara fir din familia UC. Daca este nevoie de mai multe zone, se mai poate invata o centrala JA-6x ca subsistem (arhitectura Master sau Slave). Centrala master primeste informatii de la centrala subsistem, putand, de asemenea, arma sau dezarma aceasta centrala subsistem.

Modulul telefonic "X" poate comunica cu un dispecerat de monitorizare, trimite 2 mesaje vocale, trimite 5 mesaje SMS prin serverul SMS. De asemenea, poate comunica cu un PC la distanta (folosind softul ComLink si un modem JA-60U).

Operarea si programarea sunt posibile de la o tastatura JA-60E (fie direct cablata la centrala, fie de la distanta, folosind modemul JA-60U). Centrala echipata cu un modul radio (63KR, 63KRX) poate fi programata si operata de la o tastatura fara fir, precum si prin controale de la distanta pe linie telefonica R-11 sau R-22 sau prin tastatura de la distanta Ja-60D. Operarea si programarea sunt posibile si prin softul ComLink (local sau de la distanta prin modemul JA-60U).

Specificatii electrice:

• Alimentare - 230 Vca, max 0,1 A, supravegheata, clasa II
• Baterie de back-up - 12 V, de la 1,3 sau 2,6 Ah, durata normala de viata 5 ani
• Iesire de alimentare de back-up - 13Vcc, curent max permanent de 0,4 sau 1,2 A timp de cel mult 15 min (1 ciclu pe ora), autoconsum al centralei de 30mA
• Intrari pe cablu - 4 zone de intrare, trigerare selectabila: NC, rezistenta EOL sau EOL dublu
• Reactiile zonelor - selectabile: instantanee, cu intarziere, panica, de incendiu, 24 ore, la urmatoarea intarziere
• Zone fara fir - 16 zone (2 detectori pot fi invatati la fiecare zona = pana la 32 detectori in total)
• Frecventa de lucru - 433,92 MHz; cod saritor digital; comunicatie supravegheata
• Tastaturi - max. 4 tastaturi JA-60E pe fir, max. 8 tastaturi JA-60F fara fir** sau telecomenzi RC-11 sau JA-60D**
• Coduri de acces - Cod master si 14 coduri de utilizator. Cand sistemul este impartit, codurile, detectorii si telecomenzile pot fi adresate pe sectoare particulare
• Intrari pe cablu - Contacte uscate pe releu de alarmA 1A/60V; oesiri programabile PgX & PgY (Chime, Incendiu, Armare, Panica, Alarma, Usa, Casa, Cadere alimentare), iesire de sirena (12 V, 0,7 A)
• Iesiri fara fir - Centrala transmite semnale penru date de sirena si PgX, PgY pentru UC-2xx
• Memorie de evenimente - Ultimele 127 evenimente, incluzand data, ora si specificatii detaliate
• Comunicator telefonic - modul 65X: comunicatie digitala la dispeceratul de monitorizare, 5 mesaje text sau apelare pe pager, 2 mesaje vocale, comunicatie pe modem cu un PC la distanta (ComLink SW + JA-60U modem), acces de la distanta cu tastatura prin JA-60E si JA-60U

Tastatura wireless Jablotron JA-60F

Specificatii tehnice

• power supply: 6 V - 4 AAA alkaline batteries (50 uA) or 12 V DC / 100 mA power adaptor
• battery life time: typ. 1 year
• number of keypads in a system: max. 8 control devices
• working range: max. 80 m (open area)
• access codes: identical with control panel (1 +14)
• working environment: indoor use, -10 to +40 C
• complies with: EN 50131-1 grade 2, EN 300220

Detector de miscare PIR wireless Jablotron JA-60P

Detector PIR wireless alimentat la baterii alcaline 3V, domeniu de acoperire 12m/120 de grade, viteza de detectie de la 0.1m/s pana la 4m/s. Raza de actiune max. 100m. Include baterii

Specificatii tehnice

• detection method - dual PIR sensor with digital processing
• power - 3 V - 2 x AAA battery 1.5V
• battery life time about 1 year
• nstallation height from 2 to 2.5 meters
• domeniul de acoperire 12m / 120°
• viteza de detectie 0,1 m/s to 4 m/s
• start up time 60 seconds
• raza de actiune max. 100 m (open area)
• complies with EN 50131-1 class 2

Contact magnetic wireless Jablotron JA-60N

Contact magnetic wireless alimentat la baterii de 3V. Raza de actiune max. 100m. Include baterii.

Specificatii tehnice

• power 3 V - 2 x AAA battery 1.5V
• battery life time about 1 year
• battery life time about 1 year
• built in sensor magnetic reed contact
• external sensor inputs INP & TAMP (balanced loops)
• complies with RTTE Directive EN 50131-1 grade 2
• working environment class II (indoor use, -10 to +40°C)
• declaration of conformity Phoenix Test-Lab Germany

Buton sonerie fara fir (wireless) Jablotron RC-28

Buton sonerie fara fir. Compatibil cu UC-260, UC-280, UC-216 si UC-222.

Specificatii tehnice

• Power 6 V battery (L1016 type)
• Battery life time typically 1 year
• Frequency 433.92 MHz
• Operating environment Outdoor sheltered
• Operating temperature from -20 oC to +50 oC
• Operating humidity from 25 % to 75 %
• Storage temperature from -20 oC to +70 oC
• Complies with EN ETSI 300220, ETS 300683 and EN 50134.

Sirena de interior Jablotron UC-260

Sirena de interior fara fir pentru centralele JA-60X, cu functia de clopotel si functia de sonerie. Compatibil doar cu centrala Jablotron JA-63KRX (JA-63KRG)

Specificatii tehnice

• detection method - dual PIR sensor with digital processing
• power - 3 V - 2 x AAA battery 1.5V
• battery life time about 1 year
• installation height from 2 to 2.5 meters
• domeniul de acoperire 12m / 120°
• viteza de detectie 0,1 m/s to 4 m/s
• start up time 60 seconds
• raza de actiune max. 100 m (open area)
• complies with EN 50131-1 class 2

Sirena exterior Jablotron JA-63A

The JA-63A siren is designed for outdoor use. It is powered by its own AC adapter and has a built in backup battery. The siren communicates wirelessly with the control panel (two way communication). It contains a high powered siren and a flashing light with a coloured lens.

In addition to signaling alarms, it can also provide arming and disarm-ing chirps. The siren makes regular auto testing and reports its condi-tion regularly to the system for full supervision. Built in tamper sensors trigger an alarm if there is any attempt to tamper with the siren. Only one JA-63A siren can be used with a JA-6x control panel.

Specificatii tehnice

• Power 230VAC, 50Hz (optional 110)
• Back up battery 6V, 1.3Ah
• Working range up to 100m (open area)
• Siren piezo electric, 118dB
• Siren timer 60 seconds
• Flash light timer 5 minutes
• Cover class IP44
• Working environment outdoor use, -25 to +60°C
• Complies with EN 50131-1, class 2
